BV Wire Model

BV wire is abbreviated as plastic copper wire, and its name is: general-purpose single-core hard conductor non-sheathed power cable. BV line is the abbreviation of BTV WIRE: B stands for category: wiring, T stands for conductor: copper conductor, V stands for insulation: polyvinyl chloride.

The BV line is divided into: ZR-BV and NH-BV.

ZR-BV: Copper core PVC insulated flame-retardant wire, flame retardant is added to the insulation material, and it will not spontaneously ignite away from open flames.

NH-BV: Copper core PVC insulated fire-resistant wire, which can be used normally under normal fire conditions.

BV wire use: general-purpose single-core hard conductor non-sheathed cable, suitable for cables and wires of power plants, household appliances, instruments and telecommunication equipment with AC voltage of 450/750V and below.

Features of BV line: It has the characteristics of acid and alkali resistance, oil resistance, moisture resistance, and mildew resistance.

Wire Model And Name:

1. Classification and use: It is used to distribute electric current and belongs to the category of cloth wires, which is indicated by the letter "B";

2. The conductor material is copper, which is indicated by the letter "T", and the copper core conductor in the wiring is omitted to indicate;

3. The insulating material is polyvinyl chloride, which is represented by the letter "V";

4. The structure of the silk cloth is simple. In addition to the above three points, some have sheaths. The sheath material is also indicated by the letter "V"; the sheath material is rubber. The letter "X" means. There is no need to prove that there is no sheath and no back. For example, BVV refers to copper core PVC insulated PVC sheathed round wire.

Common BV WIRE: 0.75, 1, 1.5, 2.5, 4, 6, 10, 16, 25, 35, 50, 70, 95, 120, 150, 185, 240mm2, etc.

BV flexible wire is represented by BVR, BV rubber-plastic copper wire is represented by BX, BV rubber-plastic aluminum is represented by BLX, BV plastic-aluminum is represented by BLV, fire-resistant BV wire is represented by NH-BV, and flame-retardant BV wire is represented by Flame-retardant BV wire is represented by ZR-BV

Uses: ordinary insulated wires, household wires, are commonly used wire types.
